GIS Synchronized Hoist (GPS) for long and bulky loads
Back to catalog

GIS GPS Synchronized Lifting Electric Chain Hoists for Long Loads 500–5000 kg

SKU root: GIS-GPS | Market: EN | Locale: en
Price Configure your crane below — live price, weight and shipping update as you choose.
Categories: Electric Chain Hoists
Volume pricing — save up to 12% Discount is calculated automatically on the cart subtotal.
QuantityDiscount
1 unit —
2 −3%
3–4 −5%
5–9 −8%
10+ −12%

+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.

Configure your crane

Select capacity, span and options. Price, weight and shipping update live.

Step 0 — required

How will you use this hoist?

Pick the closest match. Each duty class has its own capacity envelope: the heavier the use, the lower the rated weight. Selecting a class lighter than your real-world use voids the manufacturer warranty and risks motor failure. If unsure, pick the highest expected class — the hoist you actually need.

1 Total lifting capacity (2 hooks) — kg
2 Lift height — m
3 Power supply

GPS synchronised pairs are built for 3-phase mains only — 3 × 400 V is the workshop standard. 1-phase versions are not catalogued.

4 Lifting speed / chain falls

Two-speed NF (8/2 m/min per hook) is the GPS standard — the slow stage gives precise, level positioning of long goods. SF doubles the speed at half capacity (1 fall only). The N FU / NL FU versions are frequency-controlled with soft start for swing-free handling. 2-fall setups halve the speed and double the capacity.

5 Hook distance (centre to centre)

The distance between the two load hooks is defined in advance and built at the factory — match it to your typical goods (roughly 2/3 of the load length). From 3000 mm the connection shaft gets an additional support bearing, which steps the kit price. GPS 1000 pairs start at 800 mm.

6 Safety radio remote control

Wireless 2-button pendant with emergency stop — ONE radio drives the central control in hoist A, so the whole synchronised pair follows a single transmitter. 42 V is the standard control voltage for 3-Ph hoists.

7 Operating data counter

Records operating hours, cycles and overloads for maintenance planning. Requires the 42 V control voltage (standard on 3-Ph GPS pairs).

Need a tailored offer?

Send us your requirements through the quote form — this product will be prefilled and you can add more items in one request.

Request a quote

The GIS GPS synchronised models pair two GP electric chain hoists on a rigid connection shaft: both chains rise and fall in perfect sync, so long or bulky goods stay level without an operator balancing two pendants. The central control switches both motors simultaneously and the load hangs on two hooks at a factory-set distance matched to your goods.

Key features

  • Two electric chain hoists connected by a rigid shaft — absolutely parallel lifting and lowering of long transport goods, both motors switched simultaneously by the central control in hoist A
  • The geared limit switch sits in hoist B and acts for both hoists through the mechanical connection
  • Direct chain outlet — the pair lifts twice the nominal load of the single hoists: GPS 500 up to 2 × 1250 kg, GPS 1000 up to 2 × 2500 kg (2 chain falls)
  • Hook distance defined by the customer in advance and built at the factory: 700 mm to 5000 mm (GPS 1000 from 800 mm); from 3000 mm the connection shaft is additionally supported
  • Rotatable eyebolt suspensions (standard) allow driving on curves in suspension systems
  • Speed profiles: two-speed NF 8/2 m/min (default), fast SF 16/4 m/min, or frequency-controlled N FU / NL FU with soft start for swing-free handling of delicate long goods
  • Motors protected by temperature monitoring as standard; delivered fully equipped — chains levelled, end positions set, hoists electrically connected
  • Optional safety radio remote control (one 2-button radio drives the whole pair) and operating data counter
  • Protection class IP33, insulation class F, load hooks DIN 15401; 3-phase mains 3 × 400 V / 50 Hz
  • Complies with the Machinery Directive 2006/42/EC

Technical overview

  • Model / SKU: GIS-GPS (GPS 500 / GPS 1000)
  • Product family: Electric Chain Hoists
  • Total load capacity: 500–5000 kg (2 × 250 to 2 × 2500 kg, two hooks)
  • Hook distance: 700–5000 mm, factory-set (GPS 1000 from 800 mm)
  • Lift height: 3–12 m (3 m of chain per hoist included)
  • Lifting speed: 8/2 m/min (NF), 16/4 m/min (SF), FU 2.4–9.6 / 1.2–6.9 m/min (1 fall)
  • Duty class: A3/M3–A7/M7 depending on profile and capacity
  • Power supply: 3 × 400 V / 50 Hz (3-phase only)
  • Protection class: IP33
  • Typical use: steel service centres, timber and panel handling, formwork, long pipes and profiles, pre-assembly of façade elements

Configure total capacity, lift height, duty class, speed profile and hook distance online, then add the synchronised pair to the cart or quote list. Every configuration is priced from the current GIS factory price list.
