Electric walkie straddle stacker with 1000-1500 kg capacity and 1600-5600 mm lift height, AC control system with regenerative braking, multi-function BDI display and roll-out side battery.
Key features
- Modern AC control system with regenerative braking
- Multi-function display with hour meter and battery discharge indicator (BDI)
- Emergency reversing device and emergency power disconnect
- Stepless speed control with automatic deceleration
- Built-in pressure relief valve protects the truck against overloads
- Lifting limit switch shuts off the pump motor at maximum lift height
- Water-proof and dust-proof vertical drive motor with small turning radius
- Dividable, exchangeable mast and frame
Technical overview
- Model / SKU: EVV10-PV_EVV12-PV_EVV15-PV
- Product family: Full Electric Stackers
- Load capacity: 1000 kg, 1200 kg, 1500 kg
- Lift height: 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm, 4500 mm, 5000 mm, 5600 mm
- Initial lift: no
- Engine type: AC
- Folding platform: no
- Electric power steering: no
- Battery type/voltage/capacity: GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/225
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1000 kg, 1200 kg, 1500 kg |
|---|---|
| Lift height | 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm, 4500 mm, 5000 mm, 5600 mm |
| Initial lift | no |
| Engine type | AC |
| Folding platform | no |
| Electric power steering | no |
| Battery type/voltage/capacity | GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/225 |
