Counterbalanced Electric Reach Stacker (EVVP12C-P/EVVP15C-P) 1250-1500 kg 2500-5600 mm
Price
From 11.050,00 EUR
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
In stock — ships from local warehouse
Shipping quoted post-order
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Counterbalanced Electric Stackers
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Request quote
Share your project details and we will get back with a tailored quote.
Counterbalanced electric reach stacker with rider platform, 1250-1500 kg capacity and 2500-5600 mm lift height, German special-steel mast and multi-valve regulating lever.
Key features
- Counterbalanced design without straddle legs — works with any pallet type
- Two lifting cylinders placed on the outer sides of the mast
- Mast made of special steel imported from Germany
- AC frequency-conversion traction motor with regenerative braking
- Tilting forks make loading and stacking easy
- Combined magnetic and regenerative braking extends friction-plate life
- Multi-valve regulating lever, emergency stop switch and electrical lock
- Adjustable regulator valve controls mast lowering speed
- Magnet-suction battery cover for simple installation and upkeep
Technical overview
- Model / SKU: EVVP12C-P_EVVP15C-P
- Product family: Counterbalanced Electric Stackers
- Load capacity: 1250 kg, 1500 kg
- Lift height: 2500 mm, 3000 mm, 3500 mm, 4000 mm, 4500 mm, 5000 mm, 5500 mm, 5600 mm
- Initial lift: no
- Engine type: AC
- Folding platform: yes
- Electric power steering: option
- Battery type/voltage/capacity: LA/24/270, LFP/24/225
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1250 kg, 1500 kg |
|---|---|
| Lift height | 2500 mm, 3000 mm, 3500 mm, 4000 mm, 4500 mm, 5000 mm, 5500 mm, 5600 mm |
| Battery type/voltage/capacity | 24v-225ah, 24v-270ah |
| Initial lift | no |
| Engine type | AC |
| Folding platform | yes |
| Electric power steering | option |
