Electric Pallet Truck for Two Pallets (EPV20-I/EPV20LD-I) 2000 kg 800-2500 mm
Price
From 8.010,00 EUR
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
In stock — ships from local warehouse
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Electric Pallet Trucks
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Request quote
Share your project details and we will get back with a tailored quote.
Double-pallet electric truck with initial lift: 120 mm leg lift negotiates ramps and bridging plates, carries two pallets at once with 2000 kg total capacity and mast options up to 2500 mm.
Key features
- Carries two pallets at the same time — 2000 kg total capacity
- 120 mm initial lift negotiates ramps and bridging plates
- Emergency reverse switch on the tiller head
- Built-in pressure relief valve protects against overload
- Stepless speed control with turtle speed switch
- Vertical driving wheel gives a small turning radius
- Dividable, exchangeable mast and floating balance wheel
Technical overview
- Model / SKU: EPV20-I_EPV20LD-I
- Product family: Electric Pallet Trucks
- Load capacity: 2000 kg
- Engine type: AC
- Load capacity - mast fork: 1000 kg
- Load capacity - lower fork: 2000 kg
- Load center: 600 mm
- Load distance, center of drive axle to fork: 802 mm, 831 mm
- Fork height, lowered: 90 mm
- Tyre size, front: 250x70mm
- Tyre size, rear: 80x70mm
- Additional wheels (dimensions): 127x57mm
- Number of wheels, front/rear (x=driving) Φ: 1X+2/4
- Height, mast lowered: 1082/1212/1382mm
- Max. lift height: 1600 mm, 2000 mm, 2500 mm, 800 mm
- Initial lift: yes
- Height of tiller min/max: 780/1230mm
- Overall length: 1760 mm, 1962 mm
- Length to face of forks: 608 mm, 862 mm
- Overall width: 682 mm, 775 mm
- Fork dimensions: 60x180x1100mm, 60x180x1150mm
- Width overall forks: 550 mm, 570/650mm
- Aisle width for pallets 1000x1200mm: 1972 mm, 2238 mm
- Aisle width for pallets 800x1200mm: 2022 mm, 2288 mm
- Turning radius: 1422 mm, 1705 mm
- Travel speed, laden/unladen: 4.5/5.2km/h, 6.0/6.0km/h
- Lifting speed laden/unladen: 0.03/0.04m/s, 0.06/0.11m/s
- Lowering speed laden/unladen: 0.05/0.045m/s, 0.12/0.13m/s
- Folding platform: no
- Electric power steering: no
- Battery type/voltage/capacity: LA/24/160, LA/24/210, LFP/24/100, LFP/24/125
- Battery weight: 160 kg, 196 kg
- Battery dimensions (I/W/H): 645x148x560mm, 750x170x580mm
- Service weight (with battery): 600 kg, 950 kg
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Max. lift height | 800 mm, 1600 mm, 2000 mm, 2500 mm |
|---|---|
| Battery type/voltage/capacity | 24v-100ah, 24v-125ah, 24v-160ah, 24v-210ah |
| Load capacity | 2000 kg |
| Engine type | AC |
| Load capacity - mast fork | 1000 kg |
| Load capacity - lower fork | 2000 kg |
| Load center | 600 mm |
| Load distance, center of drive axle to fork | 802 mm, 831 mm |
| Fork height, lowered | 90 mm |
| Tyre size, front | 250x70mm |
| Tyre size, rear | 80x70mm |
| Additional wheels (dimensions) | 127x57mm |
| Number of wheels, front/rear (x=driving) Φ | 1X+2/4 |
| Height, mast lowered | 1082/1212/1382mm |
| Initial lift | yes |
| Height of tiller min/max | 780/1230mm |
| Overall length | 1760 mm, 1962 mm |
| Length to face of forks | 608 mm, 862 mm |
| Overall width | 682 mm, 775 mm |
| Fork dimensions | 60x180x1100mm, 60x180x1150mm |
| Width overall forks | 550 mm, 570/650mm |
| Aisle width for pallets 1000x1200mm | 1972 mm, 2238 mm |
| Aisle width for pallets 800x1200mm | 2022 mm, 2288 mm |
| Turning radius | 1422 mm, 1705 mm |
| Travel speed, laden/unladen | 4.5/5.2km/h, 6.0/6.0km/h |
| Lifting speed laden/unladen | 0.03/0.04m/s, 0.06/0.11m/s |
| Lowering speed laden/unladen | 0.05/0.045m/s, 0.12/0.13m/s |
| Folding platform | no |
| Electric power steering | no |
| Battery weight | 160 kg, 196 kg |
| Battery dimensions (I/W/H) | 645x148x560mm, 750x170x580mm |
| Service weight (with battery) | 600 kg, 950 kg |
