ENDO ATEX Pneumatic Chain Hoist (ATC Series) 60/125 kg
Price
From 2.820,00 EUR
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
In stock — ships from local warehouse
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Pneumatic Chain Hoists
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Request quote
Share your project details and we will get back with a tailored quote.
Japanese-made ATEX pneumatic chain hoist ATC-60K-5 / ATC-125K-5 for 60 and 125 kg loads with controls integrated on the bottom hook, a 3 m alloy-steel load chain (4x12 mm) and adjustable lifting speeds up to 20 m/min — for fast, one-handed load handling in explosive atmospheres.
Key features
- Capacities 60 and 125 kg (ATC-60K-5 / ATC-125K-5)
- Controls integrated on the bottom hook for one-handed operation
- Lifting speeds: 60 kg model 14/17.5/20 m/min, 125 kg model 6.5/10.5/12 m/min
- Standard 3 m load chain (4x12 mm), extendable
- Air pressure 0.4-0.6 MPa, air inlet Rc 3/8
- Net weight only 14.3 / 14.5 kg, headroom 790 mm
- Mounts on standard or pneumatic push/geared trolleys
- ATEX certified — safe for use in potentially explosive atmospheres
- Stepless variable speed control for precise load positioning
- Self-cooling air motor — unlimited lifts and duty hours, no overheating
- Alloy-steel load chain with excellent toughness and wear resistance
- Robust, compact and lightweight construction, made in Japan
- Compressed air must be filtered and lubricated; indoor use, -10 to 50 °C
Technical overview
- Model / SKU: ENDO-ATC
- Product family: Pneumatic Chain Hoists
- Capacity: 125 kg, 60 kg
- Chain length: 2 m
- Chain diameter: 4x12mm
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 60 kg, 125 kg |
|---|---|
| Capacity | 125 kg, 60 kg |
| Chain length | 2 m |
| Chain diameter | 4x12mm |
