Electric Rider Straddle Stacker (EVV10PV-P/EVV12PV-P/EVV15PV-P) 1000-1500 kg 1600-5600 mm
Price
On request
In stock — ships from local warehouse
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Full Electric Stackers
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Request quote
Share your project details and we will get back with a tailored quote.
Electric rider straddle stacker with 1000-1500 kg capacity and 1600-5600 mm lift height, straddle legs, brushless AC motor, side battery and damping cushion for low-noise operation.
Key features
- Folding rider platform for fast, long-distance warehouse runs
- Brushless AC motor — no carbon brush replacement
- Multi-function display with BDI and hour meter
- Roll-out side battery is easy to maintain and replace
- Damping cushion gives low-noise operation
- Emergency reversing device in the handle and turtle low-speed switch
- Automatic deceleration and built-in pressure relief valve
- Braking in both upright and horizontal handle positions
Technical overview
- Model / SKU: EVV10PV-P_EVV12PV-P_EVV15PV-P
- Product family: Full Electric Stackers
- Load capacity: 1000 kg, 1200 kg, 1500 kg
- Lift height: 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm, 4500 mm, 5000 mm, 5600 mm
- Initial lift: no
- Engine type: AC
- Folding platform: yes
- Electric power steering: option
- Battery type/voltage/capacity: GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/225
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1000 kg, 1200 kg, 1500 kg |
|---|---|
| Lift height | 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm, 4500 mm, 5000 mm, 5600 mm |
| Initial lift | no |
| Engine type | AC |
| Folding platform | yes |
| Electric power steering | option |
| Battery type/voltage/capacity | GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/225 |
