Electric reach stacker with hydraulic multi-valve control of reach, tilt and lifting, 1250-1500 kg capacity, 2500-5500 mm lift height and 500 mm fork reach — built for very narrow aisle warehouses.
Key features
- Compact reach stacker built for very narrow aisle warehouses
- Hydraulic multi-valve controls fork reach, fork tilt and lifting/lowering
- Single-scissor fork reach of 500 mm; double reach up to 1200 mm optional
- Disassemble-type platform and protection arm
- Multi-function display with BDI and hour meter
- Low centre of gravity ensures safe operation
- Dividable, exchangeable mast and frame
Technical overview
- Model / SKU: EVV12DS_EVV15DS
- Product family: Electric Reach Stackers
- Load capacity: 1250 kg, 1500 kg
- Lift height: 2500 mm, 3000 mm, 3500 mm, 4000 mm, 4500 mm, 5000 mm, 5500 mm
- Initial lift: no
- Engine type: AC
- Folding platform: yes
- Electric power steering: option
- Battery type/voltage/capacity: LA/24/320, LA/24/460, LFP/24/225
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1250 kg, 1500 kg |
|---|---|
| Lift height | 2500 mm, 3000 mm, 3500 mm, 4000 mm, 4500 mm, 5000 mm, 5500 mm |
| Initial lift | no |
| Engine type | AC |
| Folding platform | yes |
| Electric power steering | option |
| Battery type/voltage/capacity | LA/24/320, LA/24/460, LFP/24/225 |
