Low-profile hydraulic lift table with loading ramp, 1000-2000 kg capacity and a lowered height of only 85-105 mm, so no floor pit installation is needed.
Key features
- Designed for industrial use; thanks to the very low closed height no floor pit is required
- Power pack and control system housed in a separate IP54-protected external unit
- Lifting platform equipped with a safety contact frame that blocks lowering when an obstacle is detected
- 24 V control box mounted on the external housing with integrated UP, DOWN and STOP buttons
- External unit fitted with an overload relief valve and a compensated flow valve for controlled lowering speed
- Three-phase 380 V / 50 Hz power supply
- Integrated safety valve stops lowering in case of hose failure
- Transport eye bolts allow easy relocation and installation
- Lifting shafts are maintenance-free (no lubrication required)
- Quick-fit hydraulic hose coupling
- Manufactured to all applicable European safety standards, including EN 1570:1999
- Loading ramp included as standard equipment
Technical overview
- Model / SKU: NPS
- Product family: Low-Profile Lift Tables
- Load capacity: 1000 kg, 1500 kg, 2000 kg
- Platform length: 1450 mm, 1600 mm
- Platform width: 800 mm, 1000 mm, 1140 mm, 1200 mm
- Lowered height: 85 mm, 105 mm
- Lift height: 860 mm, 870 mm
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1000 kg, 1500 kg, 2000 kg |
|---|---|
| Platform length | 1450 mm, 1600 mm |
| Platform width | 800 mm, 1000 mm, 1140 mm, 1200 mm |
| Lowered height | 85 mm, 105 mm |
| Lift height | 860 mm, 870 mm |
