Light Toolholder Pillar Jib Crane (LSDS) 270° 50-100 kg
Price
Configure your crane below — live price, weight and shipping update as you choose.
Categories:
Pillar Jib Cranes
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Configure your crane
Select capacity, span and options. Price, weight and shipping update live.
Save your configuration
Get a shareable link, email the PDF to yourself, and we will save the configuration on our side.
Reset configuration?
All option selections (duty class, capacity, lift speed, trolley, options…) will return to their defaults. Your current quantity and delivery address will be kept. This cannot be undone.
Request quote
Share your project details and we will get back with a tailored quote.
The LSDS (Comege PFTL) is the standard light toolholder 270° pillar jib crane: a self-standing steel column anchored to the floor, carrying an overbraced triangulated boom that swings 270° over a workstation. It is built for indoor use, is manual-slewing only, and ships with a load trolley and cable trolley included.
Key features
- 270° partial rotation on a floor-anchored pillar with an overbraced triangulated light hollow-section boom
- Capacity 50-100 kg; spans 2-5 m; standard height under beam 3 m, adjustable in 0.1 m steps up to 4 m (above 4 m on request)
- Toolholder design — carries balancers, vacuum lifters and tools (not a hoist); one load trolley plus cable/hose trolley(s) are included
- Indoor use only; manual slewing — this crane type cannot be motorized
- Floor fixation by a bolt-down splitable base plate with a chemical-anchor kit
- Grinding SA 2.5 + 60 µm C2 polyester powder paint, RAL 1028 yellow finish (other RAL on request)
- Theoretical deflection under nominal load ≈ 1/250 of (span + height)
- Complies with the Machinery Directive 2006/42/EC
Technical overview
- Model / SKU: LSDS (Comege PFTL)
- Product family: Pillar Jib Cranes
- Load capacity: 50 / 80 / 100 kg
- Span: 2-5 m
- Rotation: 270° partial rotation (manual)
- Height under beam: 3 m standard, adjustable to 4 m
- Finish: RAL 1028 yellow (C2, indoor only)
Configure capacity, span, height under beam, fixation, finish and trolley accessories, then add the product to the quote list for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 50 kg, 80 kg, 100 kg |
|---|---|
| Span | 2 m, 3 m, 4 m, 5 m |
| Rotation | 270° partial rotation |
| Brand | DELACCO |
| Comege Model | PFTL |
| Compliance | {"machinery_directive": "2006/42/EC"} |
| Capacity [kg] | Spans [m] | Base price [€] |
|---|---|---|
| 50 | 2-5 | 1 287-1 633 |
| 80 | 2-4 | 1 287-1 588 |
| 100 | 2-3 | 1 287-1 378 |
Base price is for the standard 3 m height under beam and includes one load trolley plus cable/hose trolley(s); each extra 0.1 m of height, fixation and additional trolleys are priced in the configurator. This crane is a manual-slewing (270°) painted-steel toolholder for indoor use and cannot be motorized.
