Quadruple Scissor Lift Table (CHS) 400-2000 kg
Price
From 4.250,00 EUR
From 3.825,00 EUR
Sale
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
In stock — ships from local warehouse
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
High-Lift Hydraulic Tables
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Request quote
Share your project details and we will get back with a tailored quote.
Quadruple scissor hydraulic lift table series with capacities from 400 to 2000 kg and lift heights up to 4800 mm for multi-floor load transfer.
Key features
- Industrial lift tables designed for intensive use
- Series complies with EN 1570:1 and ANSI/ASME safety standards
- Can be installed above ground or recessed into a floor pit
- Aluminium safety contacts on the lower platform edge prevent injuries during lowering
- 24 V control box
- Internal power pack with overload relief valve and compensated valve for regulated lowering speed
- Cylinder-integrated drain system with a check valve that stops lowering in case of hose failure
- Automatic lubrication of the lifting points
- Eye bolts make installation easier
- AC motor drive
- Lift tables can also be manufactured to customer-specific requirements
Technical overview
- Model / SKU: CHS
- Product family: High-Lift Hydraulic Tables
- Load capacity: 400 kg, 800 kg, 1600 kg, 2000 kg
- Platform length: 1700 mm, 2000 mm
- Platform width: 1000 mm, 1200 mm
- Lowered height: 600 mm, 710 mm, 800 mm, 950 mm
- Lift height: 4100 mm, 4250 mm, 4800 mm
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 400 kg, 800 kg, 1600 kg, 2000 kg |
|---|---|
| Platform length | 1700 mm, 2000 mm |
| Platform width | 1000 mm, 1200 mm |
| Lowered height | 600 mm, 710 mm, 800 mm, 950 mm |
| Lift height | 4100 mm, 4250 mm, 4800 mm |
