Electric Walkie Pallet Stacker (EVV10/EVV12/EVV15) 1000-1500 kg 1600-5600 mm
Price
From 8.550,00 EUR
Select configuration
Choose attribute values to resolve the exact variant, SKU and price.
Choose all attributes to lock a variant.
In stock — ships from local warehouse
Shipping estimate
This product
—
Weight
—
Packaging
—
Your cart
—
Select your delivery country for an instant freight estimate.
Categories:
Full Electric Stackers
Volume pricing — save up to 12%
Discount is calculated automatically on the cart subtotal.
| Quantity | Discount |
|---|---|
| 1 unit | — |
| 2 | −3% |
| 3–4 | −5% |
| 5–9 | −8% |
| 10+ | −12% |
+3% bundle promo when this order combines items from at least two product categories (e.g. a hoist + a jib crane). Combined with volume pricing, total savings can reach 15%.
Request quote
Share your project details and we will get back with a tailored quote.
Full electric walkie pallet stacker with 1000-1500 kg capacity and 1600-5600 mm lift height, AC drive with regenerative braking, stepless speed control and emergency reversing device.
Key features
- Modern AC control system with regenerative braking
- Multi-function display with hour meter and battery discharge indicator (BDI)
- Emergency reversing device and emergency power disconnect
- Stepless speed control with automatic deceleration
- Built-in pressure relief valve protects the truck against overloads
- Lifting limit switch shuts off the pump motor at maximum lift height
- Water-proof and dust-proof vertical drive motor with small turning radius
- Dividable, exchangeable mast and frame
Technical overview
- Model / SKU: EVV10_EVV12_EVV15
- Product family: Full Electric Stackers
- Load capacity: 1000 kg, 1200 kg, 1500 kg
- Lift height: 1600 mm, 2500 mm, 3000 mm, 3300 mm, 3500 mm, 4500 mm, 5000 mm, 5600 mm
- Initial lift: no
- Engine type: AC
- Folding platform: no
- Electric power steering: no
- Battery type/voltage/capacity: GEL/24/120, LA/24/200, LA/24/240, LA/24/300, LFP/24/125, LFP/24/225
Order online or send a quote request for delivery terms and customer-specific configurations.
Attributes
| Load capacity | 1500 kg |
|---|---|
| Lift height | 3500 mm, 4500 mm |
| Battery type/voltage/capacity | 24v-125ah |
| Initial lift | no |
| Engine type | AC |
| Folding platform | no |
| Electric power steering | no |
