GIS Electric Hoist for Food Industry
* you can add products to the inquiry list (we usually respond to inquiries the same day) * …
On request
Back to catalog
GIS Electric Hoist with Manual Handle
Price
On request
Categories:
Special-Purpose Hoists
Request quote
Share your project details and we will get back with a tailored quote.
GIS electric hoist with manual grip
The model with a control handle enables the economical transfer of small loads such as boxes or boxes.
The standard model is equipped with fast and slow lifting, which allows precise placement of the load. For particularly sensitive handling, the chain electric hoist can be equipped with a frequency converter (inverter) so that accelerations and lifting speeds can be finely adjusted.
The control unit is firmly connected to the load handling attachment; this enables easy handling of the load with just one hand. For safe and quick lifting of the load, the lifting device can be adapted to the load being transported.
All these features make the GPH crane an ideal manipulator for workplaces with many repetitive tasks. It can be used stationary or ideally in combination with a GISKB crane system or a slewing crane.
Standard features:
- electric chain hoist for quick and easy positioning of loads
- operating an electric chain hoist and guiding the load with one hand
- control unit with switch for left and right hand control
- end positions of the hook adjustable with a limit switch
- ideal for combination with GISKB swivel or hanging crane
- option: practical kit for retrofitting GIS standard electric chain hoists
- option: with frequency converter
- option: custom cargo handling devices
Possible additional options:
- working and control voltages for all regions of the world
- load handling using a load hook or connecting piece
- suspension hook
- working hours counter
- temperature monitoring to protect the engine from overheating
- brake with manual release
- frequency converter (inverter)
- manual suspension trolley
- chain release mechanism
Technical specifications:
- maksimalna Load capacity (1 ili 2 lanca): GPMH250: 250kg, GPH500: 500kg
- standardni voltages: 3 × 400V/50Hz, 3 × 230V/50Hz
- 3-phase motor: 1 or 2 lifting speeds
- control: 42V low voltage control
- protection class: IP65
- suspension: suspension with eyebolt
- standard lifting height: GPMH250: 3m, GPH500: 4m
- control unit for left and right hand control
- control switch: ergonomic control switch with emergency stop and external stress relief
- limit switch: limit switches with gear for the highest and lowest position of the hook
- insulation class (engine): F
- brake: DC spring brake
- overload protection: sliding clutch adjustable and not in flow force
Attributes
| Weight | 19 kg |
|---|---|
| Dimensions | 40 × 25 × 57 cm |
| Load capacity | 250kg, 500kg |
| Dužina lanca | 3m, 4m |
Delivery is arranged per project and destination. Typical lead times are confirmed after technical validation and order confirmation.
- Transit method: palletized or crate shipment depending on model size.
- Scope: delivery terms and customs handling are agreed per destination country.
- Support: we provide packing list and shipping documentation with each shipment.
Final delivery terms are confirmed in the commercial offer for the selected tenant market.
