Electric Hoist with Frequency Inverter (GIS GPFU)

Electric hoist with frequency converter

Frequency-controlled electric chain hoists GPFU have successfully proven themselves in various applications. They are often used in very demanding working conditions with long working periods and a high switching frequency, such as shift work.

The 2 lifting speeds are infinitely programmable and can be optimally adapted to all modes of use. In addition to specially adapted speeds for precise positioning of the load, the acceleration and braking range can also be ideally adjusted to avoid load oscillation.

Standard features:

• electric chain hoist with frequency converter
• electric cranes with inverter
• adapted for applications with high switching frequency and operation in gear stages
• lifting speed up to 9.6 m/min.
• with a soft start for precise and gentle positioning of the load
• lifting and lowering the load without exceeding, accurate positioning of the load in combination with a frequency-controlled motorized trolley
• the speed and range of lifting and movement are programmable and adapted to the application
• protection class IP65
• option: motorized cart with frequency converter
• option: wireless remote control
• option: load-dependent lifting

Technical specifications:

• maksimalna Load capacity (1 ili 2 lanca): GPFU250: 320/630kg, GPFU500: 630/1250kg, GPFU1000: 1250/2500kg, GPFU1600: 2000/5000kg, GPFU2500: 3000/6300kg
• standard voltage: 3 × 400V/50Hz
• 3-phase motor: 2 lifting speeds with infinite adjustment
• control: 24 V/DC low voltage control
• protection class: IP65
• eyebolt suspension
• standard lifting height: 3m
• control switch: ergonomic control switch with emergency stop and external stress relief
• length of the control cable: 1.8 m
• limit switch: limit switches with gear for the highest and lowest position of the hook
• insulation class (engine): F
• brake: DC spring brake
• overload protection: sliding clutch adjustable and not in flow force
• frequency converter location: GPFU250/500/1000 in chain hoist housing, GPFU1600/2500 in external control box

Possible additional options:

• other working voltages on request
• drugi control voltages na request
• one-handed operation with a control handle on the lower hook
• suspension hook
• cargo hook with safety closure
• gear limit switch and two additional emergency stops
• working hours and switch-on counter
• temperature monitoring - protection of the engine from overheating
• brake with manual release
• chain containers for different lifting heights
• electric and manual suspension trolleys
• grease for low temperatures or use in the food industry
• radio remote control
• lifting slings or handles
• option: load-dependent lifting
